描述
| 厚钢管（水、煤、气管） | 薄钢管（电缆管） | |||||
| Thick steel pipe (water, coal, gas pipe) | Thin steel pipe (cable pipe) | |||||
| 型号 | 适配软管 | 公制 | 外径/壁厚 | 公制 | 外径/壁厚 | 包装:个 |
| Model | Fitting Hose（φ） | Metric | Outer Diameter /Wall Thickness | Metric | Outer Diameter /Wall Thickness | Std.Pkg （Pcs） |
| GLS-HCR-G3/8-13 | φ13 | #12 | 17/2.25 | #15 | 15.87/1.6 | 100 |
| GLS-HCR-G1/2-16 | φ16 | #15 | 21.25/2.75 | #20 | 19.05/1.8 | 100 |
| GLS-HCR-G3/4-20 | φ20 | #20 | 26.75/2.75 | #25 | 25.4/1.8 | 50 |
| GLS-HCR-G1-25 | φ25 | #25 | 33.5/3.25 | #32 | 31.75/1.8 | 50 |
| GLS-HCR-G11/4-32 | φ32 | #32 | 42.25/3.25 | #40 | 38.1/1.8 | 25 |
| GLS-HCR-G11/2-38 | φ38 | #40 | 48/3.5 | #50 | 50.8/2 | 25 |
| GLS-HCR-G2-51 | φ51 | #50 | 60/3.5 | #70 | 63.5/2.5 | 10 |
| GLS-HCR-G21/2-64 | φ64 | #70 | 75.5/3.75 | #80 | 76.2/3.2 | 10 |
| GLS-HCR-G3-75 | φ75 | #80 | 88.5/4 | 2 | ||
| GLS-HCR-G4-100 | φ100 | #100 | 114/4 | 2 | ||
